1500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial

  • 1500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial
  • 1500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial
  • 1500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial
Place of Origin China
Brand Name Xicheng
Model Number TYB90-8-1.5-3000
Minimum Order Quantity 1PCS
Price $120-580/PCS
Delivery Time 7-15 work days
Payment Terms L/C,T/T
Supply Ability 500PCS 15-20work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Rare Earth Permanent Magnet Motor Frequency 100-200Hz
Speed 1500-3000rpm Efficiency 88.6%-95.3%
Installation Mode B3/B35 Working System S1
Output 0.75-15Kw Voltage 380V
Highlight

1500r/m Rare Earth Permanent Magnet Motor

,

3000r/m Rare Earth Permanent Magnet Motor

,

pmsm motor for Industrial
You can tick the products you need and communicate with us in the message board.
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Voltage (V) 380 380 380 380 380 380 380 380 380 380 380 380
Erequency (Hz) 200 200 200 200 167 167 167 100 100 200 200 200
Output (Kw) 0.75 1.1 1.5 2.2 3 4 5.5 5.5 7.5 7.5 11 15
Speed (rpm) 3000 3000 3000 3000 2500 2500 2500 1500 1500 3000 3000 3000
Efficiency (%) 88.6 89.8 90.9 91.8 92.6 93.3 93.9 92.1 92.6 94.5 95 95.3
Working system S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1
Insulation grade B B B B B B B B B B B B
Installation mode B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35 B3/B35
Leave a Message
Type TYB80-8-0.75-3000 TYB80-8-1.1-3000 TYB90-8-1.5-3000 TYB90-8-2.2-3000 TYB112-8-3-2500 TYB112-8-4-2500 TYB132-8-5.5-2500 TYB132-8-5.5-1500 TYB132-8-7.5-1500 TYB132-8-7.5-3000 TYB132-8-11-3000 TYB132-8-15-3000
Product Description

1500-3000rpm Rare Earth Permanent Motor for Industrial Applications

Product Description:

Introducing the Rare Earth Permanent Magnet Motor, a permanent magnetic motor designed to meet the needs of a wide variety of applications. This powerful motor features a high efficiency rating of 88.6%-95.3%, and its output ranges from 0.75-15Kw. It is designed with a S1 working system and can be installed with B3/B35 modes. With its robust design and superior performance, the Rare Earth Permanent Magnet Motor is the perfect choice for any application.



Technical Parameters:

Parameter Value
Product Name Rare Earth Permanent Magnet Motor
Insulation Grade B
Installation Mode B3/B35
Voltage 380V
Frequency 100-200Hz
Speed 1500-3000rpm
Working System S1
Efficiency 88.6%-95.3%
Output 0.75-15Kw


Applications:

Rare Earth Permanent Magnet Motor – Xicheng TYB90-8-1.5-3000

The Xicheng TYB90-8-1.5-3000 Rare Earth Permanent Magnet Motor is a highly efficient, reliable, and durable electric motor. It is designed with rare earth permanent magnets, making it one of the strongest and most powerful electric motors on the market. It offers an insulation grade of B and a frequency range of 100-200Hz, with speeds up to 3000rpm.

The Xicheng TYB90-8-1.5-3000 is available at a competitive price, with a minimum order quantity of 1PCS. Delivery time is 7-15 work days, and payment terms include L/C and T/T. The company also offers an incredible supply ability of 500PCS in 15-20 work days, making it an ideal choice for bulk orders.



Support and Services:

Rare Earth Permanent Magnet Motor Technical Support and Services

We provide technical support and services for our Rare Earth Permanent Magnet Motors in order to ensure our customers get the best performance out of their product. Our support team is available to answer any questions you have about the product and to help troubleshoot any issues you may have. We also offer a range of services to customize the motor to meet your specific needs and to ensure it is running optimally.

Our services include:

  • Customization of the motor design to meet your specific requirements
  • Troubleshooting and maintenance services
  • Software and firmware updates

If you have any questions or need assistance with your Rare Earth Permanent Magnet Motor, please contact us and we will be happy to help.

1500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial 01500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial 11500 - 3000r/M Rare Earth Permanent Magnet Motor For Industrial 2

FAQ:

Q1:What is the brand name of the Rare Earth Permanent Magnet Motor?
A1:The brand name of the Rare Earth Permanent Magnet Motor is Xicheng.
Q2:What is the model number of the Rare Earth Permanent Magnet Motor?
A2:The model number of the Rare Earth Permanent Magnet Motor is TYB90-8-1.5-3000.
Q3:Where is the Rare Earth Permanent Magnet Motor from?
A3:The Rare Earth Permanent Magnet Motor is from China.
Q4:What is the minimum order quantity of the Rare Earth Permanent Magnet Motor?
A4:The minimum order quantity of the Rare Earth Permanent Magnet Motor is 1PCS.
Q5:What is the price range of the Rare Earth Permanent Magnet Motor?
A5:The price range of the Rare Earth Permanent Magnet Motor is $120-580/PCS.
Tags:

1500rpm Rare Earth Permanent Magnet Motor

3000rpm Rare Earth Permanent Magnet Motor

electric magnetic motor 15Kw
